Product Hightlight

• NoiselessThe built-in synchronizer of the inkjet machine can be more accurate and prevent the failure of the inkjet caused by jitter or uneven movement.
• Body-integralThe body nozzle is integrated, spraying one code at a time, which is easy to trace the product quality and ensure the quality of the control code
• Metal printing buttonMetal button, increase service life, feel better; When the display interface is finished, press the metal button to print or stop printing.
• Intelligent touch-screen system

The new inkjet printing system changes the print quality from the bottom, flattens the operating system, and makes it more spiritual and convenient.

Specification

Nozzle：TlJ thermal inkjet printhead

External l/0：USB, Serial port

Print Distance：2~5mm

Resolution：Up to 600dpi

Print Bold：0~15 times (selectable)

Backlight Time：0~90s or steady on

Backlight Intensity：0~100%

Print Height：Min:1mm,Max:12.7mm

Print Type：Water/42ml, Solvent/42ml

Ink Colors：Black,White,Red,Yellow,Blue, Green,Invisible

Data supported：Chinese,English,Numerals, Symbols, OR Codes,Barcodes,lmages, Dates, Counters

Applications： Cartons, Stones, Pipes, Cables, Metals, PlasticsElectronic Components, Automotive Parts, etc.

Battery Specification：16.8v,2000mA/h

Adapter Specification：100-240v ACInput, 50/60HzABS

Machine Material:ABS

Machine Dimension:235*135*100mm

Machine Weight:750g

Environment:Temp:0-45°C(20-30°c best),Humidity:40-60%Rh

Application

Plates, Cartons, Stones, Pipes, Cables, Metals, Plastics, Electronic Components, Automotive Parts, etc.
